    EDM refers to Electrical Discharge Machining. It is a controlled process of metal removal. This is done with the help of electric spark erosion. In the EDM process, electric spark acts as a cutting tool, and helps erode material from the work piece. Thus, a finished part of required shape can be formed with this process. This process helps achieve high level of accuracy, and is an effective solution for challenging machining applications. There are different types of EDM processes. However, wire EDM process is one of the most popular types, which is employed in a number of industries. Wire EDM, which is also referred to as spark EDM, is an electro thermal production process where the wire is submersed in deionized water. An electric current is run through the wire, creating an electrical spark of intense heat up to 12000°C). The electrical spark cuts the material by removing the metal content through melting and vaporization. This content is flushed away from the work piece with high pressure flushing. This process has some characteristic properties, which makes it easy to machine precision components and complex parts. BDE Inc., is one of the leading providers of wire EDM services. We have 27 years’ experience in complex wire electrical discharge machining parts.

    Capabilities of Wire EDM Services Provided by BDE Inc.

    The following wire EDM service capabilities has allowed us serve clients effectively.

    1. We can provide you with high-quality and precision-made products that are manufactured using 4 axis EDM cutting.

    2. The cutting tolerances of the wire EDM cutting are up to +/- .0001.

    3. We can deliver wire diameters of 0.006 ʺ, 0.008 ʺ, 0.010 ʺ, and 0.012 ʺ.

    4. We provide wire EDM services for wide and large table travel measuring up to 13.7″ x 19.68″.

    5. The cutting head “Z axis” can have a height of 11.8″.

    6. The wire EDM services that we provide have the capability of delivering tapered cuts up to 45 degrees. This is based on the height of the work piece.

    7. We use the most advanced machinery and tooling, which helps expedite the setups for production and prototype runs.

    8. We make use of several CAM software, which helps us improve the adaptability of importing drawings, files, or parts.

    Conventional chip making machinery introduces heat into the materials in order to cut them. Without applying any heat, it becomes a tough task to cut or mold them. However, with wire EDM, you can cut metals without applying any heat to them. This process is best suited for good conductors of electricity. Some materials, which are compatible with this technique, include carbon steel, kovar, Inconel, bronze, carbon graphite, titanium, stainless steel, copper, tungsten, and Hastelloy.

    Industries Using EDM?

    Electrical discharge machining services are used widely in the following industries:

    1. Medical Device Manufacturing: As wire EDM machining makes it possible to cut or mold materials like steel without heating it, this method is an ideal choice of medical device manufacturers. With this method, the manufacturing of several life-saving instruments made from carbon steel becomes easier.

    2. Tool, Die and Mold Making: With the help of EDM machining, it is possible to create very fine holes and profiles. Thus, electrical discharge machining is often used in the production of Molds, dies and Custom tools & Fixtures.

    3. Military and Aerospace Applications: EDM is used widely in the military and aerospace industries to produce parts for important equipment. EDM are used to cut several aerospace parts.

    4. Automotive Industry: In a competitive automotive industry, it is necessary to have short cycle times, and cutting costs. These are offered by EDM. Owing to its efficiency and accuracy, automotive manufacturers also turn to wire EDM.

    Applications of Wire EDM:

    Owing to its versatility, manufacturers use wire EDM for a wide range of applications as follows:

    • Prototype or production

    • Coinage die making

    • Small hole drilling

    • Mechanical parts machining

    • Metal disintegration machining

    • Mold machining

    With a huge experience to back us, BDE Inc. can provide you the best-in-class services in wire electrical discharge machining. We have served a wide range of industries, including aerospace, food, medical, military, marine, electronics, semiconductors, and so on. Do you want to know more about our wire EDM services? Please get in touch with us today. You can give us a call on 503.648.7418 or you mail us your requirements at info@bdeinc.com



    Wire EDM Specifications capabilities

    Processes Small Hole Electrical Discharge Machining
    Wire EDM Machining
    Equipment Capabilities CNC Control Capabilities
    Industry Focus Aerospace
    Agricultural
    Architectural
    ATV
    Electronic
    Energy
    Food
    Machine Tool
    Marine
    Military
    Medical & Pharmaceutical
    Motorsports
    Intended Applications Bushings
    Carburetor Components
    Engine components
    Fittings
    Machine components
    Manifolds
    Shafts
    Spacers
    Transformer Monitoring Devices
    Materials (Metals) Alloy Steels
    Aluminum
    Brass
    Bronze Alloys
    Carbide
    Carbon Steel
    Cobalt
    Copper
    Molybdenum
    Nickel
    Stainless Steel
    Steel
    Materials
    (Exotic & Precious Metals)
    Inconel
    Molybdenum
    Monel
    File Formats 3D ACIS Model File
    AutoCAD (DWG,DXF)
    BMP
    DXF
    GIF
    IGES
    Inventor (IDW, IPT)
    IronCAD (ICD,ICS)
    JPG or JPEG
    MasterCam (MDX, MC8, MC9, SET)
    PDF
    Pro-E or Pro/Engineer (DRW,PRT,XPR)
    SolidWorks (SLDPRT,SLDDRW,SLDDRT)
    STEP
    SAT
    TIFF
    Additional Capabilities Assembly Service
    CAD Design Services
    CAM Programming ServicesWelding
    Cutting Axis 2-Axis
    3-Axis
    4-Axis
    5-Axis
    Efficiency Lights Out Manufacturing
    Equipment Mitsubishi FA20 Wire EDM
    Sodick KC1 Z Small Hole EDM
    Industry Standards ANSI – American National Standards Institute
    ASME – American Society of Mechanical Engineers
    ASTM – American Society for Testing and Materials
    ISO – International Organization for Standardization
    Mil-Spec – Military Specifications
    RoHS (Compliant) – Restriction of Hazardous Substances
    Production Volume Max: 1,000 units
    Min: 1 units
    Prototype to Low Volume
    Specialty Production Shop
    Lead Times Available Max: 2 weeks
    Min: 1 Week
    Quoted on job by job basis
    Part Length 20 in
    508 mm
    Max
    Part Width 14 in
    355.6 mm
    Max
    Part Height 11.5 in
    292.1 mm
    Max
    Tolerances ±.0001 in
    ±.0025mm
